Horizontal Machining Center THM6380A

Author：CVVT.SIANJIA FLOW CONTROL Public Time：2014-04-23 Views：1873

Machine characteristic：
With a T type machine base, the machine is in a high rigidity and with no vibration when machining.
With a taper structure, it makes sure worktable’s positioning accuracy, as well as a reliable repeatability.
The spindle is with gear transimmit, it realized high torque cutting.

Technical Parameters：
Pallet size: 630X630mm
Max.tool diameter: Ф950mm
Positioning accuracy: 0.008mm
Repeat positioning accuracy: 0.004mm
B axis positioning accuracy: 8″
B axis repeat positioning accuracy: 4″
